Interrupteur Différentiel AC, 4P 63A

Interrupteur modulaire AC 4P.

Technical data for design verification

Standards

IEC/EN 61008

Rated operational voltage [Ue][Ue]Rated operating voltage [Ue]

230/400 V AC

Rated frequency [f]

50 Hz

Limit values of the operating voltageTest circuit

196 - 456 V AC

Rated insulation voltage [Ui ]

440 V

Rated impulse withstand voltage [Uimp]

4 kV

Rated short-circuit strength [Icn]

10 kA

Rated making and breaking capacity / Rated residual making and breaking capacity [Im / IΔm]

500 A

lifespanElectrical [Operations]

≧ 4000

lifespanMechanical [Operations]

≧ 20000
